Xgimi-4-Home-Assistant

XGIMI integration for home assistant.
Please give me a star 🤩 if you like it.

📦Install

Manually

1. Download the latest source code xgimi.zip from Releases
2. Unzip and copy the folder xgimi into home assistant custom_components
3. Restart home assistant

Via HACS

1. Install HACS if you do not have that already
2. In the Home Assitant HACS Tab, click on the three dots at the top right
3. Choose Custom repositories
4. Paste https://github.com/manymuch/Xgimi-4-Home-Assistant/ to the repository field, choose the Integration category and click ADD
5. Close the dialog
6. Disable the repository filter (hit CLEAR on the right of the Filtering by Downloaded text)
7. Type Xgimi to the Search bar and select Xgimi Projector Remote
8. Click DOWNLOAD on the bottom right
9. Click DOWNLOAD in the dialog that just appeared
10. Restart home assistant

🛜Get BLE token

The integration communicates with xgimi projector by UDP using local IP except for the poweron command. Once the projector is powered off, the only way to turn up is sending a special ble advertisement. Such a ble advertisement contains a special token called manufacture data. The manufacture data is different for each device even for same model.

This token can be obtained using Home Assistant's built-in Bluetooth Advertisement Monitor.

1. Open the Bluetooth Advertisement Monitor

You can access the monitor directly from your Home Assistant instance:

👉 Open Bluetooth Advertisement Monitor

Alternatively, navigate manually:

1. Go to Settings → Devices & Services → Bluetooth → Configure.
2. Select Advertisement Monitor.

This view displays all Bluetooth Low Energy (BLE) advertisement packets detected by your Bluetooth adapter.

2. Identify the Xgimi Remote MAC Address

Because the BLE environment may contain dozens of nearby devices, it’s helpful to filter results by MAC address.

If you don’t know the remote’s MAC address:

1. Pair your Xgimi remote temporarily with an Android phone.

   1. To pair the remote, turn off the projector completely or go to another room and simultaneously press and hold the Back and Home buttons until the indicator light flashes.
   2. Look for a device with the name “XGIMI RC” or “BLuetooth 4.0 RC” and pair with it.

2. In the Bluetooth settings, open Device details to find the MAC address.

3. Note down the first three bytes (the prefix). For example, in many cases XGIMI remotes begin with 1C:.

4. After that, pair the remote with the projector again.

You can later use this prefix to narrow down advertisements in the HA monitor.

3. Filter and Locate the Manufacturer Data

1. In the Advertisement Monitor, apply a MAC prefix filter (e.g., 1C:) to reduce noise.
2. Turn off your projector so that the remote control does not automatically connect to it.
3. Press the Power button on the remote to send a special BLE advertisement frame.
4. Look for entries where the Manufacturer data field is populated and has an entry with ID: 70. This data is a hexadecimal payload broadcast by the remote and contains the BLE token required by the integration.

Example frame data:

{
"name": "BLuetooth 4.0 RC",
"address": "1C:XX:XX:XX:XX:XX",
"rssi": -66,
"manufacturer_data": {
    "13": "383800000001",
    "70": "51f55a6d78e450ffffff0000000b000d"
},
"service_data": {},
"service_uuids": [
    "00001812-0000-1000-8000-00805f9b34fb"
],
"source": "30:24:XX:XX:XX:XX",
"connectable": true,
"time": 1761087659.0729098,
"tx_power": null,
"raw": "0000000000000c0000000f0f000000000e0000000000000000000d000000"
}

Copy the full value from the manufacturer data with ID 70 — this is the token required for integration configuration. In this example: 51f55a6d78e450ffffff0000000b000d.

🏗️Setup

1. Prepare the following:

   • host: local IP of the projector, check the router or the setting in the projector's menu. (For all commands via LAN: poweroff, volume, etc.)
   • token: BLE token to power on the projector. (For poweron command only, via bluetooth signals)

2. Make sure your projector is powered on and can be reached via LAN by home assistant.

3. Add new integration, search for xgimi

4. Enter your projector information, for example:

   name: z6x
   host: 192.168.0.115
   token: 51F55A6D78E450FFFFFF0000000B000D

📺How to use

The integration setup up a remote entity: e.g. remote.z6x.
Example usage of remote.send_command service:

action: remote.send_command
data:
    command: volumeup
target:
    entity_id: remote.z6x

Available commands:
The below commands work for all models:

play, pause, power, back, home, menu, right, left,
up, down, volumedown, volumeup,
poweron, poweroff, volumemute

The below commands may only work for some models, you can have a try and good luck :-)

autofocus, autofocus_new,
manual_focus_left, manual_focus_right,
motor_left_overstep, motor_left_start,
motor_right_overstep, motor_right_start, motor_stop,
shortcut_setting, choose_source, hibernate, xmusic

Dashboard example

See tv-card-example.yaml for a dashboard example using tv-card

Troubleshoot

1. If you are running Home Assistant with docker, make sure HA is accessible to the bluetooth, see issue #12.
2. Make sure the bluetooth signal from HA host machine can reach the projector without blockage.

More Related threads about BLE token

• issue #5
• issue #31
• issue #54 Thanks @mik-laj for contributing usage of advertisement monitor in HA.
• stackoverflow discussion

TODO

• auto discovery
• media player entity

Contributions and suggestions are welcome!
